A Comprehensive Range of PCB Assembly Services

Benefits

For the best in service at G&B we seek to deliver added value benefits, including:

• Investment in the latest technology assembly equipment (see capabilities and plant list)
• Latest technology in cleaning facilities
• A highly skilled IPC certified workforce
• A fully air conditioned ESD controlled and certified factory
• Experienced Project Managers
• Planning team who will set up, control, monitor and validate your product manufacture.
• Serial number control and traceability
• ERP Database Control
• IPC certified
• RoHS and NON RoHS assembly and rework facilities

Capabilities

The capability to operate the most efficient systems and processes is assured by our experience and resources across:

• SMT PCB Assembly - prototypes to volume assembly
• BGA and µBGA Assembly - prototypes to volume assembly
• Mixed Technology PCB Assembly ­ prototypes to volume assembly
• Axial, Radial and PTH Assembly - prototypes to medium volume assembly
• Placement speeds ranging from 3,500 to 27,000 components per hour
• RoHS and Non RoHS processes
• Smallest component 01005’s
• Smallest pitch 30 microns
• Tallest component 15mm
• Largest component / connectors 45 x 100mm
• Placement of all fine-pitch QFP, BGA, µBGA, CSP packages
• PCB size capability from 50 x 50mm to 460 x 440mm
• Six SMT pick and place lines
• Cleaning Facilities
• 50 manual assembly stations
• Conformal Coating
• Labelling / traceability / serial number control

Quality

With Quality as paramount in manufacturing, at G&B we have undertaken the following to ensure that our process control and product quality is at the top of its game, standards include:

• ISO 9001:2008,
• IPC-A-610D (Inspection)
• IPC J-STD-001D (Assembly)
• IPC 7711/7721A (Rework)
• ISO 14001 (environmental) final stages  pre audit.
• BS EN 61340-5-1/2 (ESD)

In addition to these standards we also have the following Medical quality standards enabling us to CE Mark medical product on behalf of our customers:-

• FDA Registered and Inspected
• ISO 13485:2003
• Directive 93/42/EEC for Medical Devices Annex II (3),
• Canadian MDR SOR/98 ­ 282
• Certification for the accreditation of foreign manufacturings in Japan

Established as a supplier to the US, Canada, Japan and Europe, G&B Manufacturing Services are well placed in the international market for delivering global solutions, understanding primary regulatory bodies and the subsequent demands on businesses across industry standards. Please contact us for more information on 01420 474 188 or email us to understand how we can help your business in these markets.

General:

• All pick and place lines are regularly serviced under maintenance contracts
• All equipment is calibrated to our internal calibration schedule
• All processes and procedures are regularly audited both internally and externally.
• We maintain full operator to serial number traceability.


Plant List

At G&B our investment in production facilities ensures that small, medium and volume assembly quantities are all catered for competitively, with our extensive range including:

Fritche Machine x 2 for hand build SMT Prototyes

ASSEMBLY LINE 1 (17400 CPH)

PANASONIC SP28P-DHU SCREEN PRINTER
ASSEMBLÉON OPAL XII PICK & PLACE MACHINE
ASSEMBLÉON MG1 PICK & PLACE MACHINE
BTU PYRAMAX 98 REFLOW OVEN
ATS TRAY SEQUENCER
JOT CONVEYORS AND BOARD EXIT STACKER

ASSEMBLY LINE 2 (27000 CPH)

PANASONIC SP28P-DU SCREEN PRINTER
PANASONIC CM202-DU CHIP MOUNTER
PANASONIC CM301-DU CHIP MOUNTER
QUAD IV C1 CHIP MOUNTER
BTU PYRAMAX 98 REFLOW OVEN
JOT CONVEYORS AND BOARD EXIT STACKER

ASSEMBLY LINEs 3 and 4 (7000 CPH EACH)

SM TECH SCREEN PRINTER
QUAD QSP2 PICK & PLACE MACHINE
BTU VIP 70 REFLOW OVEN (LEAD FREE)
JOT CONVEYORS AND BOARD EXIT STACKER

ASSEMBLY LINE 5 (6000 CPH)

DECK 248 SCREEN PRINTER WITH VISION
EUROPLACER PROGRESS 6
BTU VIP 70 REFLOW OVEN (LEAD FREE)
JOT CONVEYORS AND BOARD EXIT STACKER

ASSEMBLY LINE 6 (2000 CPH)

DECK 250 SCREEN PRINTER
QUAD 2C PICK AND PLACE MACHINE
QUAD QCR REFLOW OVEN

QUAD 4C PICK AND PLACE MACHINE - STANDALONE

TEST

OSCILLOSCOPES
MULTIMETERS
AVOMETERS
JTAG
THANDAR TG501 5MHz FUNCTION GENERATOR
AUTOMATIC COMPONENT BRIDGE
VARIOUS POWER SUPPLIES
GALLENKAMP DRYING CABNETS
MICTOMASTER LV48
SAFETY TESTER FIGEL MODEL 233
AVO MEGGER 4K FLASH TESTER
COMARK INSULATION METER
CLARE VOLTAGE TESTER
AGILENT TECH E5062A NETWORK ANALYSER

OTHER

WAVE SOLDER RoHS ­ CMS400
WAVE SOLDER NON RoHS ELECTROVERT ASTRAPAK
OFF LINE PROGRAMMING STATION
TAPE AND REELING ­ DIMA SYSTEMS - HANDYTAPER
CAROUSEL LINVAR LINPIC 66 CAROUSEL
CONFORMAL COATING SPRAY BAY
REEL COUNTER
SENSOTRONIC AVD 500SA Co-Solvent cleaning plant
BLUNDEL SC800 STENCIL CLEANER
DGASSING STATION
CONCOAT DC-2001 (DIP CONFORMAL COATING)
KEMPNER SHRINK WRAPER
HANSAL BAG SEALER.

BGA STATION

ERSA BGA PLA500 PLACEMENT AND REMOVAL SYSTEM. ­ RoHS and NON RoHS

VISION EQUIPMENT

ORBOTECH VANTAGE S22 AOI 3D INSPECTION SYSTEM
ORBOTECH VT-8000 AOI SYSTEM
MANTIS SCOPES X 5
MEIJI MICROSCOPES X 2
ERSA SCOPE

HAND BUILD

Fritche Machine x 2 for hand build SMT Prototyes
MASCOT WORK STATIONS - MANUAL
MASCOT WORK STATIONS ­ SEMI AUTOMATIC
BLUNDELL CROPMATIC

Cleaning

The latest G&B solutions demonstrate significant environmental testing improvements and better yield during AOI.

G&B recently invested in the SENSOTRONIC AVD 500SA Co-Solvent cleaning plant which enables cleaning of no clean fluxes, the benefits of which are improved results in environmental testing and a better yield during AOI stages. These deliver our customers a faster and more competitive assembly service.

Other benefits of the Sensotronic are its environmental features which maximise cleaning performance whilst minimising solvent escape, so you can rest assured that your products are being manufactured by a company managing and continually improving its environmental programs.
